Each core is to be tested independently and requires a test wrapper cell to isolate the core from the rest of the design and provide test access at the core's I/Os. This test wrapper functions in various modes under the control of a test controller. The wrapper cell shown in Figure 1 has been customized from the default DFT Compiler wrapper to add the additional overrides to control the wrapper modes. The modes supported by this wrapper include:

• INTEST (wrp_if) mode — For testing the core logic. Wrapper cells on the input side isolate the core from capturing data from outside, and the input wrapper cells capture the scan data. Wrapper cells on the output side capture data from the core.
• EXTEST (wrp_of) mode — For testing top-level user-defined logic (UDL). The wrapper cells on the core inputs capture data from the UDL, while the wrapper cells on the output side isolate the UDL from capturing data from the core and also launch test data into the UDL. During capture, the input wrapper cells capture the scan data from the UDL.
• Internal_scan mode — For supporting traditional top-level test. The wrapper cells do not provide isolation but are treated like internal scan chains of the core, and the wrapper cells on input and output are transparent as in functional mode. This mode helps to test paths through the core I/Os while keeping all the core scan chains (including wrapper scan chains) intact. An additional override signal added to the default DFT Compiler cell helps make the cell transparent while keeping the wrapper chains intact in this mode.
• Mission mode — For supporting the design's functional mode. The wrapper cells are disabled.

Along with these wrapper modes, the test strategy uses several different test modes:

• Scan compressed mode — For testing a core. The wrapper chains are part of the scan-compression internal scan channels and are driven by the scan compression logic. For this test mode (Figure 2), wrapper cells are configured in their INTEST (wrp_if) mode.



2. Scan compressed mode for testing a core (design blocks not to scale).


Click here for a larger version

• Reconfigured scan mode — This design has two reconfigured test modes for uncompressed scan (Figure 3). The reconfigured scan mode with 17-pin scan chain interface is the default mode created as part of scan compression insertion by DFT Compiler. The second re-configured scan mode has a 90-pin scan chain interface and suits this core for designs in which a top-level scan architecture of the whole design is used for test. Wrapper chains are also part of the re-configured scan chains. The wrapper cells are configured in their INTEST (wrp_if) mode.



3. Reconfigured test modes for uncompressed scan.


Click here for a larger version

• EXTEST mode — For testing UDL. The wrapper chains are used while the scan-enable and test clocks for other core internal scan chains are gated off. In this test mode, the wrapper cells are configured in their EXTEST (wrp_of) mode (Figure 4).



4. EXTEST mode for testing user-designed logic.


Click here for a larger version

DSP example

The Qualcomm DSP core provides a good example of how to implement the core-based test strategy. With a total of about 5 million transistors, the DSP has approximately 56K scan flops arranged in 17 scan channels.

The design team for this chip developed a fully automated DFT insertion flow and integrated this flow with Synopsys Pilot Design Environment. DFT insertion was done using DFT Compiler, and this tool's wrapper-insertion features handled core isolation. DFT MAX performed scan compression. Most of steps in the implementation flow (Figure 5) are based on DFT MAX and DFT Compiler automated features, although the wrapper customizations require Design Compiler (DC) low-level commands that were automated using a design-specific script.

The core uses a hierarchical physical implementation flow. To ensure that core blocks can be designed in parallel, the DFT insertion flow was also done hierarchically. Based on the number of available IOs (17), scan flops, scan compression ratio (10X) and test clock domains (2), a balanced scan chain architecture was created. The scan chain architecture allowed mixing of edges but not clock domains. Also, the scan chains from two core design blocks (A and D) come out as is for scan compression insertion instead of merging them with scan chains from the rest of the core logic.

Table 1 summarizes the scan architecture at different levels of hierarchy where DFT insertion was performed.

Table 1 " DSP Core Scan-Architecture.
*Note: Top-level numbers are for different test modes: scan-compressed chains / reconfigured scan-mode chains / scan chains in expanded re-configured scan mode / wrapper chains in EXTEST or wrp-of test mode.

Core design blocks A and D were scan-inserted first. Scan insertion was done in Physical Compiler to avoid any re-ordering flow for these design blocks. Then scan and wrapper insertion was done at macro level. A multi-mode DFT insertion was done to achieve the required number of scan channels and wrapper chains in the respective test modes. The DFT insertion was done in the logical domain. Here is the multi-mode definition and scan configuration at macro level:

Code Example 1

Once the wrapper and scan chains were inserted, the DFT team used a custom script to customize the wrapper cells and created a new CTL (Core Test Language) model for the macro level of the design for scan compression insertion. The new CTL model was created using DFT Compiler scan extraction flow, treating wrapper chains as any other internal scan chains. Finally, scan compression insertion was done at top-level using the new macro CTL model. Again, multi-mode scan insertion was done to implement the required test modes. All the test control signals were connected to the Core JTAG Interface (CJI) in RTL. The internal-pin feature of DFT Compiler was used to define the CJI outputs as control signals. Here is the multi-mode definition and scan configuration at top-level:

Code Example 2
